Teldat C Installation Manual page 22

1 Router Installation
SDRAM size: 16 Megabytes
SIMM 0: 16 Megabytes (detected)
Caches: ON
FLASH: 8 Mb.
NVRAM: 128 Kb.
EEPROM: 2048 Bytes.
WAN: DTE
ADSL
UTOPIA
LAN SCC1
Current production date: 00 06
Current software license: 20 4
Current serial number: 359/00011
........
TRYING APP CODE DUMP
(CONFIGURED) B0080000............................................
APP DATA DUMP....................
Running application
Default configuration used
Initializing
Teldat
Modem model TELDAT C 20 4 CPU M80860
1 LAN, 1 WAN Line , 0 ISDN Lines, 1 ADSL Line
*
At this point, reset microswitch 5 to the OFF position (you don't have to turn the device off). The next time you restart
the router, the saved configuration will run.
18
Write-Back
(c)1996-2000
S/N: 359/00011
Teldat C/S/G/A Routers Family Installation Manual
Teldat S.A.
