2.3.5 POS Connector

RJ45 POS

2.3.6 ANT Connector

Teldat C/S/G/A Routers Family Installation Manual
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
POS
DCE
TxD (input)
CTS (output)
RTS(input)
GND
DTR (input)
DSR (output)
--
RxD (output)
ANT
RF in/out
GND
