Teldat C Installation Manual page 28

2 Appendix
Config Interface
LOCAL TERMINAL
CONNECTOR
Power Source
INPUT VOLTAGE
OUTPUT VOLTAGE
MAXIMUM POWER
External power supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
Teldat C6 model Power Source
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
Teldat C6 model dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
Environmental Specifications
AMBIENT TEMPERATURE
RELATIVE HUMDITY
24
V.24 9.600-8-N-1- without flow control.
RJ45 female, located on the front panel of the device.
DB9 female on the rear part of the C6 model.
+5V,+15V,-15V DC.
2000 mA (to +5V DC) and 200 mA (to +15V, -15V DC).
20 W.
100-240V AC
600 mA
50-60 Hz
45 VA
100-240V AC
1400 mA
47-63 Hz
45 W
Desktop
220 x 220 x 30 mm.
0.9 Kg.
Desktop box.
310 x 415 x 43 mm
3.25 Kg.
On: 5º to 45ºC. Off: -20º to 60ºC.
On: 8% to 85%. Off: 5% to 90%.
Teldat C/S/G/A Routers Family Installation Manual
Teldat S.A.
