Usage guidelines
This command takes effect only when the AC type is Ethernet.
When the PW type is Ethernet, the PE encapsulates packets forwarded between the AC and PW as
follows:
Traffic sent to the PW cannot carry the P-Tag.
•
If traffic from the AC has the P-Tag, the PE removes the P-Tag, adds the PW label and public
tunnel encapsulation, and forwards the traffic through the PW.
If traffic from the AC does not have the P-Tag, the PE adds the PW label and public tunnel
encapsulation and forwards the traffic through the PW.
For traffic received from the PW:
•
If the AC access mode (configured by ac interface) is VLAN, the PE adds the P-Tag and forwards
the traffic through the AC.
If the AC access mode is Ethernet, the PE directly forwards the traffic through the AC. For all AC
access mode configurations, the PE cannot modify or delete the P-Tag for the traffic from the PW.
When the PW type is VLAN, the PE encapsulates packets forwarded between the AC and PW as follows:
Traffic sent to the PW must carry the P-Tag.
•
If traffic from the AC has the P-Tag, the PE keeps the P-Tag when the peer PE does not require the
ingress to modify the P-Tag or changes the P-Tag to the expected value (which can be zero)
when the peer PE requires the ingress to modify the P-Tag. Then the PE adds the PW label and
public tunnel encapsulation, and forwards the traffic through the PW.
If traffic from the AC does not have the P-Tag, the PE adds a P-Tag of 0 when the peer PE does
not require the ingress to modify the P-Tag or adds the expected P-Tag (which can be zero) when
the peer PE requires the ingress to modify the P-Tag. Then the PE adds the PW label and public
tunnel encapsulation, and forwards the traffic through the PW.
For traffic received from the PW:
•
If the AC access mode (configured by ac interface) is VLAN, the PE modifies or keeps the P-Tag
and forwards the traffic through the AC.
If the AC access mode is Ethernet, the PE removes the P-Tag and forwards the traffic through the
AC.
Examples
# Configure the PW type as Ethernet.
<Sysname> system-view
[Sysname] pw-class pw100
[Sysname-pw-pw100] pw-type ethernet
Related commands
• ac-interface
display l2vpn pw-class
•

service-instance

Use service-instance to create a service instance on a Layer 2 Ethernet interface and enter service
instance view.
Use undo service-instance to delete a service instance.
138
