5–5 CIRCUIT BOARD DESCRIPTION
The following table lists circuit boards and their respective card cage slot assignments on the mother board of the
LOGIQ a200 system.
CARD CAGE SLOT
1
2
3
4
TABLE 5– 1
CIRCUIT BOARD DESCRIPTION
BOARD NAME
ESP BD ASSY Echo Signal Processor Board Assembly
RTC BD ASSY Real Time Controller Board Assembly
DSC BD ASSY Digital Scan Convertor Board Assembly
MST BD ASSY Master Board Assembly
CONN BD ASSY Connector Board Assembly
HV BD ASSY High Voltage Board Assembly
MOTHER ASSY Motherboard Assembly
LOGIQ a200 SERVICE MANUAL
DESCRIPTION
5–7
2138853
NOTE
DIAGRAMS
