GE MEDICAL SYSTEMS
REV 2
2–2–7

Transducer Connection

1. Connect a transducer to the left side connector slot #1, transducer receptacle as follows:
a. Ensure that the transducer twist lock lever points towards the 12 o'clock position.
b. Insert the transducer connector on the receptacle guide pin until it touches the receptacle mating surface.
c. Twist the transducer twist lock lever to the 4 o'clock position to lock it in place. Twist the lever to the 12
o'clock position to disconnect the transducer.
It is not necessary to turn OFF power to connect or disconnect a transducer.
2. Connect the main power cable to a hospital grade power receptacle with the proper rated voltage checked
during preinstallation. Never use a three–to–two prong adapter; this defeats the safety ground.
2–2–8

Moving into Position

Do not lift the unit by the Keyboard.
Do not tilt the unit more than 5 degrees to avoid tipping it over.
To avoid injury by tipping over. Set the monitor to the lowest position before moving.
Equipment Damage Possibility. Lifting the console by holding covers may damage the
covers. Do not lift the console by holding any covers.
In general, a single adult can move the LOGIQ α200. (It is better to pull from the rear rather than push from the
front of the unit). Before moving, store all loose parts in the unit. Wrap transducers in soft cloth or foam to
prevent damage.
2–2–9

Adjusting System Clock

Set system clock for the LOGIQ α200to the local time. For procedure of adjusting the System clock, refer to
"Customizing Your System" in the Users manual.
Note
CAUTION
CAUTION
2–14
LOGIQ α200 SERVICE MANUAL
2138853
INSTALLATION
