GE MEDICAL SYSTEMS
REV 5
6–2–45 Terminal Block 12 Assy (FRU No. 501)
Time Required
10 Minutes
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
Do NOT unplug the power cord before OFF the power switch.
Refer to ILLUSTRATION 6–51.
1. Turn OFF the system and unplug the power cord from the outlet.
2.
Remove the Left Cover (FRU 404). Refer to 6–2–27.
3.
Unscrew the two screws (1 and 2) and pull out the Terminal Block 12 Assy.
4.
Unscrew and Disconnect twelve ring terminals (TB2–1 ~ TB2–12). Refer to ILLUSTRATION 5–3,Chapter 5.
Cut the tie wrap, if necessary.
5.
Unscrew and Disconnect twelve ring terminals (TB2–1 ~ TB2–12).
6.
Remove the Terminal Block 12 Assy.
CAUTION
6–94
LOGIQ α200 SERVICE MANUAL
2138853
RENEWAL PARTS
