GE Medical Systems LOGIQ ?200 Service Manual page 104

GE MEDICAL SYSTEMS
REV 7
2157726, 2157727, 2157728, 2157729, 2157858, 2157730, 2157731, 2157732
2184999, 2185000, 2185001, 2185002, 2183920, 2184519, 2184520, 2184521
2205669, 2205670, 2205671, 2205672, 2205674, 2205675, 2205676, 2205677
FRU
NO. PART NAME
601 FUSE SET
602 FLAT CABLE SET
603 CABLES SET
604 HARDWARE SET
605 CABLE HOOK ARM SET
606 TOP COVER SHEET
607 BATTERY
608 PRINTER INSTALL KIT
609 PIOP2 ASSY
LOGIQ a200
MATERIAL LIST (6/7)
PART NO QTY. FRU
2148236 1 1
2148237 1 1
2148238 1 1
2148239 1 2
2170597 1 2
2158087 1 2
2160331 1 1
2176459 1 1
2181871 1 2
6–20
LOGIQ α200 SERVICE MANUAL
DESCRIPTION
1A(250V), 500mA(250V),
2A(125V)
Cable Assy 49, 51
Cable Assy
2, 3, 5, 6, 7, 8, 9, 10,
11, 12, 13, 14, 15, 16,
17, 19, 20, 21, 22, 23,
24, 25, 26, 27, 28, 29,
30, 31, 32, 33, 37, 39,
40, 41, 42, 43, 44, 45,
46, 47, 48, 61, 62, 63,
64, 65
2157994, 2166804(4),
2157951(12), 2158063,
2157971, 2157973,
2158077(2), 2160325,
2159642(10) ,
2159634(10) ,
2159625(10) ,
2162241(10) ,
2173177(5)
Include Washer
3V, CR2450
RENEWAL PARTS
2138853
SECTION FOR
REFERENCE
6–3
7–2–4
