PREINSTALLATION

2–1–1 Introduction
This section describes various general electrical, operational, and environmental considerations that must be
considered before installing the LOGIQ α200 Ultrasound unit.
2–1–2

Power Line Requirements

The following power line parameters should be monitored for one week before installation. We recommend that
you use an analyzer Dranetz Model 606–3 or Dranetz Model 626:
PARAMETER
Voltage Range
Voltage Range
Line Frequency
Power Transients
Decaying Oscillation : Less than 15 % of peak voltage for less than 1 millisecond.
: LIMITS
: Korea : 220 VAC
: USA : 115 VAC
: 220 – 240 VAC  10%(198 –264 VAC)
: Europe, LA
: Japan. : 100 VAC
: Asia : 115 VAC
: 220 – 240 VAC  10%(198 –264 VAC)
: All applications : MAX. 500 VA
: All applications : 50/60Hz ( 2Hz)
: Less than 25 % of nominal peak voltage for less than 1 millisecond for any type of
transient, including line frequency, synchronous, asynchronous, or aperiodic
transients.
2–3
LOGIQ α200 SERVICE MANUAL
10% (198 – 242 VAC)
10% (103 – 127 VAC)
10% (90 – 110 VAC)
10% (103 – 127 VAC)
