1–2–1 Warnings (Continued)
The following table describes the purpose and location of safety labels and other important information provided
on the equipment.
Label/Icon
Identification and Rating Plate
Type/Class Label
IP Code
(IPX1)
Device Listing/
Certification Labels
"DANGER – Risk of explosion used
in..."
Purpose/Meaning
Manufacturer's name and address
Date of manufacture
Model and serial numbers
Electrical ratings (Volts, Amps, phase, and
frequency)
Used to indicate the degree of safety or protec-
tion.
Indicates the degree of protection provided
by the enclosure per IEC 529. IPX1
indicates drip proof.
Equipment Type BF (man in the box symbol)
IEC 878-02-03 indicates B Type equipment
having a floating applied part.
Equipment Type CF (heart in the box
symbol) IEC 878-02-05 indicate equipment
having a floating applied part having a
degree of protection suitable for direct
cardiac contact.
Laboratory logo or labels denoting
conformance with industry safety standards
such as UL or IEC.
The system is not designed for use with
flammable anesthetic gases.
"CAUTION" The equilateral triangle is usually
used in combination with other symbols to
advise or warn the user.
"ATTENTION – Consult accompanying
documents" is intended to alert the user to
refer to the operator manual or other
instructions when complete information
cannot be provided on the label.
1–15
LOGIQ α200 SERVICE MANUAL
Location
Rear of console near power inlet
Foot Switch
Probe connectors
ECG connector and surgical probes
Rear of console
Rear of console
Various
Various
