Top Cover (Fru No. 409) - GE Medical Systems LOGIQ ?200 Service Manual

GE MEDICAL SYSTEMS
REV 5
6–2–32 Top Cover (FRU No. 409)
Time Required
5 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–38.
1. Turn OFF the system.
2.
Remove the Left Cover (FRU 404). Refer to 6–2–27.
3.
Remove the Right Cover(FRU 405). Refer to 6–2–28.
4.
Remove the Rear Cover (FRU 408). Refer to 6–2–31.
5.
Pull up the Pole Cover (FRU 403). Refer to 6–2–22.
6.
Remove the Cable Hook Arm (1)
7.
Unscrew five screws (2 – 3) and four bolts (4 –7).
8.
Remove the Top Cover.
LOGIQ α200 SERVICE MANUAL
6–72
2138853
RENEWAL PARTS
