6–2–1 Monitor Assy (FRU No. 100)
Time Required
5 Minutes
Tool Required
Screwdriver
Procedure
PERSONAL INJURY HAZARD. VIDEO MONITOR SUPPORT ARM IS SPRING LOADED.
RELEASING ARM WHEN MONITOR IS NOT INSTALLED WILL CAUSE SUDDEN UPWARD
MOVEMENT. KEEP YOUR HEAD AND BODY AWAY FROM ABOVE VIDEO MONITOR
SUPPORT ARM.
Refer to ILLUSTRATION 6–7.
1.
Turn OFF the system.
2.
Lift and set the Monitor to the highest position by pushing down the Up/down Release Button located on the
Swing Arm Assy.
3.
Remove the Monitor Bottom Cover. Refer to 6–2–4.
4.
Disconnect the connector.
5.
Unscrew one screw (1).
6.
Pull the Monitor Assy upwards.
