7–3–3 Chassis Leakage Current Test (Continued)
Data Sheet for Chassis Source Leakage Current
Follow the foregoing test procedure. The test passes when all readings measure less than the value shown in the
table below (TABLE 7– 2).
MAXIMUM ALLOWANCE LIMIT FOR CHASSIS SOURCE LEAKAGE CURRENT
COUNTRY
USA
OTHERS
Electric Shock Hazard. When the meter's ground switch is OPEN, don't touch the unit!
Unit Tester
Power POLARITY
Switch
Enter name of tested peripheral here:
ON NORM
ON NORM
ON REV
ON REV
OFF NORM
OFF NORM
OFF REV
OFF REV
TABLE 7– 2
NORMAL OPEN
CONDITION GROUND
N/A 0.3mA
0.1mA 0.5mA
CAUTION
TABLE 7– 3
DATA SHEET FOR CHASSIS SOURCE LEAKAGE CURRENT
Tester Test1
NEUTRAL Probe
or GROUND connector
Switch
OPEN
CLOSED
OPEN
CLOSED
OPEN
CLOSED
OPEN
CLOSED
7–9
LOGIQ a200 SERVICE MANUAL
REVERSE OPEN
POLARITY NEUTRAL
0.3mA N/A
0.5mA 0.5mA
Test2 Test3 Test4
wheel CRT
PERIODIC MAINTENANCE
2138853
Test5
