6–2–36 Neck Frame (FRU No. 414)
Time Required
0.5 Hours
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
Refer to ILLUSTRATION 6–42.
1. Turn OFF the system.
2.
Remove the Keyboard Assy (FRU No. 204). Refer to 6–2–10.
3.
Remove the Left Cover (FRU 404). Refer to 6–2–27.
4.
Remove the Right Cover(FRU 405). Refer to 6–2–28.
5.
Remove the Front Base Cover (FRU 406). Refer to 6–2–29.
6.
Remove the Front Cover (FRU 407). Refer to 6–2–30.
7.
Remove the Top Cover (FRU 409). Refer to 6–2–32.
8.
Remove the Printer Cover (FRU 410). Refer to 6–2–33.
9.
Remove four hexagonal bolts (1 – 4).
10.
Remove the Neck Frame (FRU No. 414).
