GE D90 Plus Communications Manual page 63

CHAPTER 2: MODBUS COMMUNICATION
Address Description
2667 Breaker 1 Interlock Open Interlock 1
2668 Breaker 1 Interlock Open Interlock 2
2669 Breaker 1 Interlock Open Interlock 3
266A Breaker 1 Interlock Events
266B ...Repeated for Breaker 2
2676 ...Repeated for Breaker 3
2681 ...Repeated for Breaker 4
268C ...Repeated for Breaker 5
2697 ...Repeated for Breaker 6
Expanded FlexState Actual Values (Read Only)
2B00 FlexState 1 Actual Value
2B01 FlexState 2 Actual Value
2B02 FlexState 3 Actual Value
2B03 FlexState 4 Actual Value
2B04 FlexState 5 Actual Value
2B05 FlexState 6 Actual Value
2B06 FlexState 7 Actual Value
2B07 FlexState 8 Actual Value
2B08 FlexState 9 Actual Value
2B09 FlexState 10 Actual Value
2B0A FlexState 11 Actual Value
2B0B FlexState 12 Actual Value
2B0C FlexState 13 Actual Value
2B0D FlexState 14 Actual Value
2B0E FlexState 15 Actual Value
2B0F FlexState 16 Actual Value
2B10 FlexState 17 Actual Value
2B11 FlexState 18 Actual Value
2B12 FlexState 19 Actual Value
2B13 FlexState 20 Actual Value
2B14 FlexState 21 Actual Value
2B15 FlexState 22 Actual Value
2B16 FlexState 23 Actual Value
2B17 FlexState 24 Actual Value
2B18 FlexState 25 Actual Value
2B19 FlexState 26 Actual Value
2B1A FlexState 27 Actual Value
2B1B FlexState 28 Actual Value
2B1C FlexState 29 Actual Value
2B1D FlexState 30 Actual Value
2B1E FlexState 31 Actual Value
2B1F FlexState 32 Actual Value
2B20 FlexState 33 Actual Value
2B21 FlexState 34 Actual Value
2B22 FlexState 35 Actual Value
2B23 FlexState 36 Actual Value
2B24 FlexState 37 Actual Value
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
MODBUS MEMORY MAP
Step Format Default
1 F300 0
1 F300 0
1 F300 0
1 F102 1 (Enabled)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
59
