MODBUS MEMORY MAP
Address Description
1350 Data Logger Channel 5 Minimum Date
1352 Data Logger Channel 5 Minimum Time
1354 Data Logger Channel 5 Average
1356 Data Logger Channel 5 Unit
135A Data Logger Channel 6 Maximum
135C Data Logger Channel 6 Maximum Date
135E Data Logger Channel 6 Maximum Time
1360 Data Logger Channel 6 Minimum
1362 Data Logger Channel 6 Minimum Date
1364 Data Logger Channel 6 Minimum Time
1366 Data Logger Channel 6 Average
1368 Data Logger Channel 6 Unit
136C Data Logger Channel 7 Maximum
136E Data Logger Channel 7 Maximum Date
1370 Data Logger Channel 7 Maximum Time
1372 Data Logger Channel 7 Minimum
1374 Data Logger Channel 7 Minimum Date
1376 Data Logger Channel 7 Minimum Time
1378 Data Logger Channel 7 Average
137A Data Logger Channel 7 Unit
137E Data Logger Channel 8 Maximum
1380 Data Logger Channel 8 Maximum Date
1382 Data Logger Channel 8 Maximum Time
1384 Data Logger Channel 8 Minimum
1386 Data Logger Channel 8 Minimum Date
1388 Data Logger Channel 8 Minimum Time
138A Data Logger Channel 8 Average
138C Data Logger Channel 8 Unit
1390 Data Logger Channel 9 Maximum
1392 Data Logger Channel 9 Maximum Date
1394 Data Logger Channel 9 Maximum Time
1396 Data Logger Channel 9 Minimum
1398 Data Logger Channel 9 Minimum Date
139A Data Logger Channel 9 Minimum Time
139C Data Logger Channel 9 Average
139E Data Logger Channel 9 Unit
13A2 Data Logger Channel 10 Maximum
36
Range Units
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
--- ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
--- ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
--- ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
--- ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
--- ---
-9999999999.999 to ---
9999999999.999
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
1 F050 0
1 F050 0
0.001 F060 0
--- F215 (None)
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
--- F215 (None)
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
--- F215 (None)
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
--- F215 (None)
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
--- F215 (None)
0.001 F060 0
