GE D90 Plus Communications Manual page 80

MODBUS MEMORY MAP
Address Description
Passwords (Read/Write Setting)
4008 Modbus Local Setting Password Setting (4 items)
Passwords (Read/Write Command)
4010 Modbus Remote Command Password Setting (4
items)
Passwords (Read/Write Setting)
4018 Modbus Remote Setting Password Setting (4 items)
Passwords (Read/Write)
4020 Modbus Command Password Entry (4 items)
4028 Modbus Setting Password Entry (4 items)
Passwords Actual Values (Read Only)
4030 Modbus Command Password Status
4031 Modbus Setting Password Status
Passwords (Read/Write Setting)
4032 Command Password Access Timeout
4033 Setting Password Access Timeout
4034 Invalid Password Attempts
4035 Password Lockout Duration
4036 Password Access Events
4037 Local Setting Auth
4038 Remote Setting Auth
4039 Access Auth Timeout
Preferences (Read/Write Setting)
4050 Language
4051 Default Front Panel Timeout
4052 Current Cutoff Level
4053 Voltage Cutoff Level
Communications (Read/Write Setting)
4070 Port 1 IP Address
4072 Port 1 IP Subnet Mask
4074 Port 1 Gateway IP Address
4076 PRT1 Ethernet Operation Mode
4077 Port 2 IP Address
4079 Port 2 IP Subnet Mask
407B Port 2 Gateway IP Address
407D PRT2 Ethernet Operation Mode
407E PRT2 Redundancy
407F Port 3 IP Address
4081 Port 3 IP Subnet Mask
4083 Port 3 Gateway IP Address
4085 Port 3 Ethernet Operation Mode
4086 COM1 Minimum Response Time
4087 RS485 Com1 Baud Rate
4088 RS485 Com1 Parity
4089 RS485 Com1 Connection
408A Modbus Slave Address
408B Modbus IP Port Number
76
Range Units
0 to 4294967295 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 1 ---
0 to 1 ---
5 to 480 min
5 to 480 min
2 to 5 ---
5 to 60 min
0 to 1 ---
0 to 65535 ---
0 to 65535 ---
5 to 480 min
0 to 3 ---
0 to 1440 min
0.002 to 0.02 pu
0.1 to 1 V
0 to 4294967295 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 2 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 2 ---
0 to 2 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 2 ---
0 to 1000 ms
0 to 9 ---
0 to 2 ---
0 to 1 ---
1 to 254 ---
1 to 65535 ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
1 F003 0
1 F003 0
1 F003 0
1 F003 0
1 F003 0
1 F102 0 (Disabled)
1 F102 0 (Disabled)
1 F001 5
1 F001 30
1 F001 3
1 F001 5
1 F102 1 (Enabled)
1 F300 1
1 F300 1
1 F001 30
1 F531 0 (English)
1 F001 60
0.001 F001 20
0.1 F001 10
1 F003 0
1 F003 0
1 F003 0
1 F192 2 (Auto)
1 F003 0
1 F003 0
1 F003 0
1 F192 2 (Auto)
1 F172 1 (Dual IP)
1 F003 0
1 F003 0
1 F003 0
1 F192 2 (Auto)
10 F001 0
1 F112 6 (19200)
1 F113 0 (None)
1 F223 0 (Local)
1 F001 254
1 F001 502
