GE D90 Plus Communications Manual page 158

MODBUS MEMORY MAP
Address Description
E640 PMU Auxiliary Voltage Test Magnitude
E642 PMU Auxiliary Voltage Test Angle
E643 PMU Phase A Current Test Magnitude
E645 PMU Phase A Current Test Angle
E646 PMU Phase B Current Test Magnitude
E648 PMU Phase B Current Test Angle
E649 PMU Phase C Current Test Magnitude
E64B PMU Phase C Current Test Angle
E64C PMU Ground Current Test Magnitude
E64E PMU Ground Current Test Angle
E64F PMU Test Frequency
E651 PMU Test df/dt
Phasor Measurement Unit Triggering (Read/Write Setting)
E652 PMU User Trigger
Phasor Measurement Unit Voltage Trigger (Read/Write Setting)
E653 PMU Voltage Trigger Function
E654 PMU Voltage Trigger Low Volt
E655 PMU Voltage Trigger High Volt
E656 PMU Voltage Trigger Pkp Time
E657 PMU Voltage Trigger Dpo Time
E658 PMU Voltage Trigger Block
E65C PMU Voltage Trigger Events
Phasor Measurement Unit RS485 Reporting Configuration (Read/Write Setting)
E65D Reserved (163 items)
Remote Devices (Read/Write Setting) (32 Modules)
E700 Remote Device 1 ID
E721 Remote Device 1 Ethernet APPID
E722 Remote Device 1 Dataset
E723 ...Repeated for Remote Device 2
E744 ...Repeated for Remote Device 2
E745 ...Repeated for Remote Device 2
E746 ...Repeated for Remote Device 3
E769 ...Repeated for Remote Device 4
E78A ...Repeated for Remote Device 4
E7AD ...Repeated for Remote Device 5
E7AE ...Repeated for Remote Device 5
E7AF ...Repeated for Remote Device 6
E7D0 ...Repeated for Remote Device 6
E7D1 ...Repeated for Remote Device 6
E7D2 ...Repeated for Remote Device 7
E7F3 ...Repeated for Remote Device 7
154
Range Units
0 to 700 kV
-180 to 180 °
0 to 9.999 kA
-180 to 180 °
0 to 9.999 kA
-180 to 180 °
0 to 9.999 kA
-180 to 180 °
0 to 9.999 kA
-180 to 180 °
20 to 70 Hz
-10 to 10 Hz/s
0 to 65535 ---
0 to 1 ---
0.25 to 1.25 pu
0.75 to 1.75 pu
0 to 600 s
0 to 600 s
0 to 65535 ---
0 to 1 ---
--- ---
0 to 16383 ---
0 to 8 ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
0.01 F003 50000
0.05 F002 0
0.001 F004 1000
0.05 F002 -1000
0.001 F004 1000
0.05 F002 -13000
0.001 F003 1000
0.05 F002 11000
0.001 F004 0
0.05 F002 0
0.001 F003 60000
0.01 F002 0
1 F300 0
1 F102 0 (Disabled)
0.001 F001 800
0.001 F001 1200
0.01 F001 10
0.01 F001 100
1 F300 0
1 F102 0 (Disabled)
--- F209 "Remote
Device 1"
1 F001 0
1 F184 0 (Fixed)
