GE D90 Plus Communications Manual page 122

MODBUS MEMORY MAP
Address Description
B40F ...Repeated for IEC 61850 GGIO4 Analog 28
B417 ...Repeated for IEC 61850 GGIO4 Analog 29
B41F ...Repeated for IEC 61850 GGIO4 Analog 30
B427 ...Repeated for IEC 61850 GGIO4 Analog 31
B42F ...Repeated for IEC 61850 GGIO4 Analog 32
IEC 61850 GSE Configuration (Read/Write Settings)
B437 Default GOOSE Update Time
B438 IEC 61850 GSSE GsEna Function
B439 IEC 61850 GSSE ID
B45A IEC 6158 GOOSE GoEna (transmission) Function
B45B IEC 61850 GSSE Destination MAC
B45E IEC 61850 GOOSE ID
B47F IEC 61850 GOSSE Destination MAC
B482 IEC 61850 GOOSE VLAN Priority
B483 IEC 61850 GOOSE VLAN ID
B484 IEC 61850 GOOSE ETYPE APPID
IEC 61850 Logical Node Name Prefixes (Read/Write Settings)
B485 IEC 61850 LPHD1 LN Prefix
B488 IEC 61850 PIOC LN Prefix (14 items)
B4B2 IEC 61850 PTOC LN Prefix (18 items)
B4E8 IEC 61850 PTUV LN Prefix (10 items)
B506 IEC 61850 PTOV LN Prefix (8 items)
B51E IEC 61850 PDIS LN Prefix (10 items)
B35C IEC 61850 RBRF LN Prefix (2 items)
B542 IEC 61850 RPSB LN Prefix
B545 IEC 61850 RREC LN Prefix
B548 IEC 61850 MMXU LN Prefix (6 items)
B686 IEC 61850 RFLO LN Prefix
B695 IEC 61850 XCBR LN Prefix (6 items)
B6A7 IEC 61850 PTRC LN Prefix (6 items)
B6B9 IEC 61850 PDIF LN Prefix
B6C5 IEC 61850 MMXN Ln Prefix
B734 IEC 61850 RSYN LN Prefix (2 items)
B73A IEC 61850 ZLIN LN Prefix (4 items)
B746 IEC 61850 XSWI LN Prefix (30 items)
B7A0 IEC 61850 CILO LN Prefix (36 items)
B80C IEC 61850 CSWI LN Prefix (36 items)
B878 IEC 61850 PSDE LN Prefix (2 items)
B87E IEC 61850 RDIR LN Prefix (2 items)
B884 IEC 61850 PTUF LN Prefix (10 items)
B8A2 IEC 61850 PTOF LN Prefix (2 items)
B8AE IEC 61850 PFRC LN Prefix (4 items)
IEC 61850 MMXU Deadbands (Read/Write Settings) (6 Modules)
B8BA IEC 61850 MMXU TotW Deadband 1
B8BC IEC 61850 MMXU TotVAr Deadband 1
B8BE IEC 61850 MMXU TotVA Deadband 1
B8C0 IEC 61850 MMXU TotPF Deadband 1
118
Range Units
1 to 60 s
0 to 1 ---
--- ---
0 to 1 ---
--- ---
--- ---
--- ---
0 to 7 ---
0 to 4095 ---
0 to 16383 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0 to 65534 ---
0.001 to 100 %
0.001 to 100 %
0.001 to 100 %
0.001 to 100 %
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
1 F001 60
1 F102 0 (Disabled)
--- F209 "GSSEOut"
1 F102 0 (Disabled)
--- F072 0
--- F209 "GOOSEOut"
--- F072 0
1 F001 4
1 F001 0
1 F001 0
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
1 F206 (none)
0.001 F003 10000
0.001 F003 10000
0.001 F003 10000
0.001 F003 10000
