CHAPTER 2: MODBUS COMMUNICATION
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
F173: Network IP update status (16-bit enumeration)
This format code indicates port status.
Enumeration Value
0 OK
1 PORT 1 NETMASK ERROR
2 PORT 2 NETMASK ERROR
3 PORT 3 NETMASK ERROR
4 PORT 1 IP ADDR RSVD
5 PORT 2 IP ADDR RSVD
6 PORT 3 IP ADDR RSVD
7 PORT 1 IP ADDR LPBK
8 PORT 2 IP ADDR LPBK
9 PORT 3 IP ADDR LPBK
10 PORT 1 IP ADDR NETWK
11 PORT 2 IP ADDR NETWK
12 PORT 3 IP ADDR NETWK
13 PORT 1 IP ADDR BDCST
14 PORT 2 IP ADDR BDCST
15 PORT 3 IP ADDR BDCST
16 PRT 1-2 SUBNET OVRLP
17 PRT 1-3 SUBNET OVRLP
18 PRT 2-3 SUBNET OVRLP
19 >1 GATEWAY DEFINED
MODBUS MEMORY MAP
177
