GE D90 Plus Communications Manual page 74

MODBUS MEMORY MAP
Address Description
2D12 Virtual Output 19 Actual Value
2D13 Virtual Output 20 Actual Value
2D14 Virtual Output 21 Actual Value
2D15 Virtual Output 22 Actual Value
2D16 Virtual Output 23 Actual Value
2D17 Virtual Output 24 Actual Value
2D18 Virtual Output 25 Actual Value
2D19 Virtual Output 26 Actual Value
2D1A Virtual Output 27 Actual Value
2D1B Virtual Output 28 Actual Value
2D1C Virtual Output 29 Actual Value
2D1D Virtual Output 30 Actual Value
2D1E Virtual Output 31 Actual Value
2D1F Virtual Output 32 Actual Value
2D20 Virtual Output 33 Actual Value
2D21 Virtual Output 34 Actual Value
2D22 Virtual Output 35 Actual Value
2D23 Virtual Output 36 Actual Value
2D24 Virtual Output 37 Actual Value
2D25 Virtual Output 38 Actual Value
2D26 Virtual Output 39 Actual Value
2D27 Virtual Output 40 Actual Value
2D28 Virtual Output 41 Actual Value
2D29 Virtual Output 42 Actual Value
2D2A Virtual Output 43 Actual Value
2D2B Virtual Output 44 Actual Value
2D2C Virtual Output 45 Actual Value
2D2D Virtual Output 46 Actual Value
2D2E Virtual Output 47 Actual Value
2D2F Virtual Output 48 Actual Value
2D30 Virtual Output 49 Actual Value
2D31 Virtual Output 50 Actual Value
2D32 Virtual Output 51 Actual Value
2D33 Virtual Output 52 Actual Value
2D34 Virtual Output 53 Actual Value
2D35 Virtual Output 54 Actual Value
2D36 Virtual Output 55 Actual Value
2D37 Virtual Output 56 Actual Value
2D38 Virtual Output 57 Actual Value
2D39 Virtual Output 58 Actual Value
2D3A Virtual Output 59 Actual Value
2D3B Virtual Output 60 Actual Value
2D3C Virtual Output 61 Actual Value
2D3D Virtual Output 62 Actual Value
2D3E Virtual Output 63 Actual Value
2D3F Virtual Output 64 Actual Value
Remote Input/Output State Actual Values (Read Only)
70
Range Units
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
1 F108 0 (Off)
