GE D90 Plus Communications Manual page 53

CHAPTER 2: MODBUS COMMUNICATION
Address Description
1A89 Source 3 Phase BG Voltage Magnitude
1A8B Source 3 Phase BG Voltage Angle
1A8C Source 3 Phase CG Voltage Magnitude
1A8E Source 3 Phase CG Voltage Angle
1A8F Source 3 Phase AB or AC Voltage RMS
1A91 Source 3 Phase BC or BA Voltage RMS
1A93 Source 3 Phase CA or CB Voltage RMS
1A95 Source 3 Phase AB or AC Voltage Magnitude
1A97 Source 3 Phase AB or AC Voltage Angle
1A98 Source 3 Phase BC or BA Voltage Magnitude
1A9A Source 3 Phase BC or BA Voltage Angle
1A9B Source 3 Phase CA or CB Voltage Magnitude
1A9D Source 3 Phase CA or CB Voltage Angle
1A9E Source 3 Auxiliary Voltage RMS
1AA0 Source 3 Auxiliary Voltage Magnitude
1AA2 Source 3 Auxiliary Voltage Angle
1AA3 Source 3 Zero-Sequence Voltage Magnitude
1AA5 Source 3 Zero-Sequence Voltage Angle
1AA6 Source 3 Positive-Sequence Voltage Magnitude
1AA8 Source 3 Positive-Sequence Voltage Angle
1AA9 Source 3 Negative-Sequence Voltage Magnitude
1AAB Source 3 Negative-Sequence Voltage Angle
1AC0 Source 4 Phase AG Voltage RMS
1AC2 Source 4 Phase BG Voltage RMS
1AC4 Source 4 Phase CG Voltage RMS
1AC6 Source 4 Phase AG Voltage Magnitude
1AC8 Source 4 Phase AG Voltage Angle
1AC9 Source 4 Phase BG Voltage Magnitude
1ACB Source 4 Phase BG Voltage Angle
1ACC Source 4 Phase CG Voltage Magnitude
1ACE Source 4 Phase CG Voltage Angle
1ACF Source 4 Phase AB or AC Voltage RMS
1AD1 Source 4 Phase BC or BA Voltage RMS
1AD3 Source 4 Phase CA or CB Voltage RMS
1AD5 Source 4 Phase AB or AC Voltage Magnitude
1AD7 Source 4 Phase AB or AC Voltage Angle
1AD8 Source 4 Phase BC or BA Voltage Magnitude
1ADA Source 4 Phase BC or BA Voltage Angle
1ADB Source 4 Phase CA or CB Voltage Magnitude
1ADD Source 4 Phase CA or CB Voltage Angle
1ADE Source 4 Auxiliary Voltage RMS
1AE0 Source 4 Auxiliary Voltage Magnitude
1AE2 Source 4 Auxiliary Voltage Angle
1AE3 Source 4 Zero-Sequence Voltage Magnitude
1AE5 Source 4 Zero-Sequence Voltage Angle
1AE6 Source 4 Positive-Sequence Voltage Magnitude
1AE8 Source 4 Positive-Sequence Voltage Angle
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
MODBUS MEMORY MAP
Step Format Default
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
49
