GE D90 Plus Communications Manual page 55

CHAPTER 2: MODBUS COMMUNICATION
Address Description
1B5E Source 6 Auxiliary Voltage RMS
1B60 Source 6 Auxiliary Voltage Magnitude
1B62 Source 6 Auxiliary Voltage Angle
1B63 Source 6 Zero-Sequence Voltage Magnitude
1B65 Source 6 Zero-Sequence Voltage Angle
1B66 Source 6 Positive-Sequence Voltage Magnitude
1B68 Source 6 Positive-Sequence Voltage Angle
1B69 Source 6 Negative-Sequence Voltage Magnitude
1B6B Source 6 Negative-Sequence Voltage Angle
Power Metering Actual Values (Read Only) (6 Modules)
1C00 Source 1 Three-Phase Real Power
1C02 Source 1 Phase A Real Power
1C04 Source 1 Phase B Real Power
1C06 Source 1 Phase C Real Power
1C08 Source 1 Three-Phase Reactive Power
1C0A Source 1 Phase A Reactive Power
1C0C Source 1 Phase B Reactive Power
1C0E Source 1 Phase C Reactive Power
1C10 Source 1 Three-Phase Apparent Power
1C12 Source 1 Phase A Apparent Power
1C14 Source 1 Phase B Apparent Power
1C16 Source 1 Phase C Apparent Power
1C18 Source 1 Three-Phase Power Factor
1C19 Source 1 Phase A Power Factor
1C1A Source 1 Phase B Power Factor
1C1B Source 1 Phase C Power Factor
1C20 Source 2 Three-Phase Real Power
1C22 Source 2 Phase A Real Power
1C24 Source 2 Phase B Real Power
1C26 Source 2 Phase C Real Power
1C28 Source 2 Three-Phase Reactive Power
1C2A Source 2 Phase A Reactive Power
1C2C Source 2 Phase B Reactive Power
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
MODBUS MEMORY MAP
Step Format Default
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
51
