MODBUS MEMORY MAP
Address Description
1AE9 Source 4 Negative-Sequence Voltage Magnitude
1BEB Source 4 Negative-Sequence Voltage Angle
1B00 Source 5 Phase AG Voltage RMS
1B02 Source 5 Phase BG Voltage RMS
1B04 Source 5 Phase CG Voltage RMS
1B06 Source 5 Phase AG Voltage Magnitude
1B08 Source 5 Phase AG Voltage Angle
1B09 Source 5 Phase BG Voltage Magnitude
1B0B Source 5 Phase BG Voltage Angle
1B0C Source 5 Phase CG Voltage Magnitude
1B0E Source 5 Phase CG Voltage Angle
1B0F Source 5 Phase AB or AC Voltage RMS
1B11 Source 5 Phase BC or BA Voltage RMS
1B13 Source 5 Phase CA or CB Voltage RMS
1B15 Source 5 Phase AB or AC Voltage Magnitude
1B17 Source 5 Phase AB or AC Voltage Angle
1B18 Source 5 Phase BC or BA Voltage Magnitude
1B1A Source 5 Phase BC or BA Voltage Angle
1B1B Source 5 Phase CA or CB Voltage Magnitude
1B1D Source 5 Phase CA or CB Voltage Angle
1B1E Source 5 Auxiliary Voltage RMS
1B20 Source 5 Auxiliary Voltage Magnitude
1B22 Source 5 Auxiliary Voltage Angle
1B23 Source 5 Zero-Sequence Voltage Magnitude
1B25 Source 5 Zero-Sequence Voltage Angle
1B26 Source 5 Positive-Sequence Voltage Magnitude
1B28 Source 5 Positive-Sequence Voltage Angle
1B29 Source 5 Negative-Sequence Voltage Magnitude
1B2B Source 5 Negative-Sequence Voltage Angle
1B40 Source 6 Phase AG Voltage RMS
1B42 Source 6 Phase BG Voltage RMS
1B44 Source 6 Phase CG Voltage RMS
1B46 Source 6 Phase AG Voltage Magnitude
1B48 Source 6 Phase AG Voltage Angle
1B49 Source 6 Phase BG Voltage Magnitude
1B4B Source 6 Phase BG Voltage Angle
1B4C Source 6 Phase CG Voltage Magnitude
1B4E Source 6 Phase CG Voltage Angle
1B4F Source 6 Phase AB or AC Voltage RMS
1B51 Source 6 Phase BC or BA Voltage RMS
1B53 Source 6 Phase CA or CB Voltage RMS
1B55 Source 6 Phase AB or AC Voltage Magnitude
1B57 Source 6 Phase AB or AC Voltage Angle
1B58 Source 6 Phase BC or BA Voltage Magnitude
1B5A Source 6 Phase BC or BA Voltage Angle
1B5B Source 6 Phase CA or CB Voltage Magnitude
1B5D Source 6 Phase CA or CB Voltage Angle
50
Range Units
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
0 to 999999.999 V
-359.9 to 0 °
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
