GE D90 Plus Communications Manual page 46

MODBUS MEMORY MAP
Address Description
1858 Source 2 Ground Current Angle
1859 Source 2 Zero-Sequence Current Magnitude
185B Source 2 Zero-Sequence Current Angle
185C Source 2 Positive-Sequence Current Magnitude
185E Source 2 Positive-Sequence Current Angle
185F Source 2 Negative-Sequence Current Magnitude
1861 Source 2 Negative-Sequence Current Angle
1862 Source 2 Differential Ground Current Magnitude
1864 Source 2 Differential Ground Current Angle
1865 Source 2 Current Reserved (27 items)
1880 Source 3 Phase A Current RMS
1882 Source 3 Phase B Current RMS
1884 Source 3 Phase C Current RMS
1886 Source 3 Neutral Current RMS
1888 Source 3 Phase A Current Magnitude
188A Source 3 Phase A Current Angle
188B Source 3 Phase B Current Magnitude
188D Source 3 Phase B Current Angle
188E Source 3 Phase C Current Magnitude
1890 Source 3 Phase C Current Angle
1891 Source 3 Neutral Current Magnitude
1893 Source 3 Neutral Current Angle
1894 Source 3 Ground Current RMS
1896 Source 3 Ground Current Magnitude
1898 Source 3 Ground Current Angle
1899 Source 3 Zero-Sequence Current Magnitude
189B Source 3 Zero-Sequence Current Angle
189C Source 3 Positive-Sequence Current Magnitude
189E Source 3 Positive-Sequence Current Angle
189F Source 3 Negative-Sequence Current Magnitude
18A1 Source 3 Negative-Sequence Current Angle
18A2 Source 3 Differential Ground Current Magnitude
18A4 Source 3 Differential Ground Current Angle
18A5 Source 3 Current Reserved (27 items)
18C0 Source 4 Phase A Current RMS
18C2 Source 4 Phase B Current RMS
18C4 Source 4 Phase C Current RMS
18C6 Source 4 Neutral Current RMS
18C8 Source 4 Phase A Current Magnitude
18CA Source 4 Phase A Current Angle
18CB Source 4 Phase B Current Magnitude
18CD Source 4 Phase B Current Angle
18CE Source 4 Phase C Current Magnitude
18D0 Source 4 Phase C Current Angle
18D1 Source 4 Neutral Current Magnitude
18D3 Source 4 Neutral Current Angle
18D4 Source 4 Ground Current RMS
42
Range Units
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
--- ---
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
--- ---
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
