GE D90 Plus Communications Manual page 76

MODBUS MEMORY MAP
Address Description
3350 Modbus File Transfer Filename 2
3378 Modbus File Transfer State 2
3379 Modbus File Transfer Position 2
337B Modbus File Transfer Block Size 2
337C Modbus File Transfer Data 2 (122 items)
Event Recorder Actual Values (Read Only)
3400 Events Since Last Clear
3402 Number of Available Events
3404 Event Recorder Last Cleared Date
Event Recorder (Read/Write Command)
3406 Event Recorder Clear Command
Event Recorder Actual Values (Read Only)
3408 Event Recorder Last Time Stamp
Miscellaneous Actual Values (Read Only)
3410 Settings File Last Change Date
3412 CPU Status
Miscellaneous (Read/Write)
3413 Front Panel Status
Miscellaneous (Read/Write Setting)
3414 Web Server Function
3415 HTTP IP Port Number
Disturbance Recorder (Read/Write Setting)
3420 Disturbance Record Function
3421 Disturbance Record Number of Records
3422 Disturbance Record Trigger Mode
3423 Disturbance Record Trigger Position
3424 Disturbance Record Analog Channel (64 items)
34A4 Disturbance Record Digital Channel (32 items)
34C4 Disturbance Record Analog Channel High Trigger (64
items)
3504 Disturbance Record Analog Channel Low Trigger (64
items)
3544 Disturbance Record Digital Channel Trigger (32 items) 0 to 3
3564 Disturbance Record Analog Channel High Pickup (64
items)
35E4 Disturbance Record Analog Channel Low Pickup (64
items)
3664 Disturbance Record Block Trigger
3665 Disturbance Record Analog Channel Block Trigger (64
items)
36A5 Disturbance Record Maximum Retriggers
Disturbance Recorder Commands (Read/Write Command)
36B0 Disturbance Record Force Trigger
36B1 Disturbance Record Clear Data
Disturbance Recorder Actual Values (Read Only)
36C0 Disturbance Record Trigger Secs (64 items)
3740 Disturbance Record Newest File Number
72
Range Units
--- ---
0 to 7 ---
0 to 4294967295 ---
0 to 65535 ---
0 to 65535 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 1 ---
0 to 4294967295 ---
0 to 4294967295 ---
0 to 2 ---
0 to 65535 ---
0 to 1 ---
1 to 65535 ---
0 to 1 ---
1 to 64 ---
0 to 1 ---
1 to 100 %
0 to 4294967295 ---
0 to 65535 ---
0 to 3 ---
0 to 3 ---
---
0 to 1000000 ---
0 to 1000000 ---
0 to 65535 ---
0 to 65535 ---
1 to 4 ---
0 to 1 ---
0 to 1 ---
0 to 4294967295 ---
0 to 65535 ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
--- F204 (none)
1 F095 0 (IDLE)
1 F003 0
1 F001 0
1 F001 0
1 F003 0
1 F003 0
1 F050 0
1 F126 0 (No)
1 F003 0
1 F050 0
1 F097 0 (Out of
Service)
1 F001 0
1 F102 0 (Disabled)
1 F001 80
1 F102 1 (Enabled)
1 F001 48
1 F118 0 (Automatic
Overwrite)
1 F001 50
1 F600 0
1 F300 0
1 F094 0 (OFF)
1 F094 0 (OFF)
1 F094 0 (OFF)
0.1 F003 10000
0.1 F003 10000
1 F300 0
1 F300 0
1 F001 2
1 F126 0 (No)
1 F126 0 (No)
0.1 F003 0
1 F001 0
