GE D90 Plus Communications Manual page 58

MODBUS MEMORY MAP
Address Description
1CAA Source 6 Phase A Reactive Power
1CAC Source 6 Phase B Reactive Power
1CAE Source 6 Phase C Reactive Power
1CB0 Source 6 Three-Phase Apparent Power
1CB2 Source 6 Phase A Apparent Power
1CB4 Source 6 Phase B Apparent Power
1CB6 Source 6 Phase C Apparent Power
1CB8 Source 6 Three-Phase Power Factor
1CB9 Source 6 Phase A Power Factor
1CBA Source 6 Phase B Power Factor
1CBB Source 6 Phase C Power Factor
Energy Metering Actual Values (Read Only Non-Volatile) (6 Modules)
1D00 Source 1 Positive Watt-hour
1D02 Source 1 Negative Watt-hour
1D04 Source 1 Positive Var-hour
1D06 Source 1 Negative Var-hour
1D08 Source 1 Energy Reserved (8 items)
1D10 Source 2 Positive Watt-hour
1D12 Source 2 Negative Watt-hour
1D14 Source 2 Positive Var-hour
1D16 Source 2 Negative Var-hour
1D18 Source 2 Energy Reserved (8 items)
1D20 Source 3 Positive Watt-hour
1D22 Source 3 Negative Watt-hour
1D24 Source 3 Positive Var-hour
1D26 Source 3 Negative Var-hour
1D28 Source 3 Energy Reserved (8 items)
1D30 Source 4 Positive Watt-hour
1D32 Source 4 Negative Watt-hour
1D34 Source 4 Positive Var-hour
1D36 Source 4 Negative Var-hour
1D38 Source 4 Energy Reserved (8 items)
1D40 Source 5 Positive Watt-hour
1D42 Source 5 Negative Watt-hour
1D44 Source 5 Positive Var-hour
1D46 Source 5 Negative Var-hour
1D48 Source 5 Energy Reserved (8 items)
1D50 Source 6 Positive Watt-hour
1D52 Source 6 Negative Watt-hour
1D54 Source 6 Positive Var-hour
1D56 Source 6 Negative Var-hour
1D58 Source 6 Energy Reserved (8 items)
54
Range Units
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
0 to 1000000000000 Wh
0 to 1000000000000 Wh
0 to 1000000000000 varh
0 to 1000000000000 varh
--- ---
0 to 1000000000000 Wh
0 to 1000000000000 Wh
0 to 1000000000000 varh
0 to 1000000000000 varh
--- ---
0 to 1000000000000 Wh
0 to 1000000000000 Wh
0 to 1000000000000 varh
0 to 1000000000000 varh
--- ---
0 to 1000000000000 Wh
0 to 1000000000000 Wh
0 to 1000000000000 varh
0 to 1000000000000 varh
--- ---
0 to 1000000000000 Wh
0 to 1000000000000 Wh
0 to 1000000000000 varh
0 to 1000000000000 varh
--- ---
0 to 1000000000000 Wh
0 to 1000000000000 Wh
0 to 1000000000000 varh
0 to 1000000000000 varh
--- ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
--- F001 0
