GE D90 Plus Communications Manual page 98

MODBUS MEMORY MAP
Address Description
68D0 Directional Comparison Unblocking Rx1
68D1 Directional Comparison Unblocking LOG1
68D2 Directional Comparison Unblocking Rx2
68D3 Directional Comparison Unblocking LOG2
68D4 Directional Comparison Unblocking Rx3
68D5 Directional Comparison Unblocking LOG3
68D6 Directional Comparison Unblocking Rx4
68D7 Directional Comparison Unblocking LOG4
68D8 Directional Comparison Unblocking Event
68D9 Reserved (6 items)
Phase Undervoltage (Read/Write Grouped Setting) (2 Modules)
7000 Phase Undervoltage 1 Function
7001 Phase Undervoltage 1 Signal Source
7002 Phase Undervoltage 1 Pickup
7003 Phase Undervoltage 1 Curve
7004 Phase Undervoltage 1 Delay
7005 Phase Undervoltage 1 Minimum Voltage
7006 Phase Undervoltage 1 Block
7008 Phase Undervoltage 1 Events
7009 Phase Undervoltage 1 Measurement Mode
700A Phase Undervoltage 1 Reserved (6 items)
7010 ...Repeated for Phase Undervoltage 2
Phase Overvoltage (Read/Write Grouped Setting) (2 Modules)
7040 Phase Overvoltage 1 Function
7041 Phase Overvoltage 1 Source
7042 Phase Overvoltage 1 Pickup
7043 Phase Overvoltage 1 Delay
7044 Phase Overvoltage 1 Reset Delay
7045 Phase Overvoltage 1 Block
7047 Phase Overvoltage 1 Events
7048 Phase Overvoltage 1 Reserved (8 items)
7050 ...Repeated for Phase Overvoltage 2
Distance (Read/Write Grouped Setting)
7060 Distance Signal Source
7061 Memory Duration
7062 Force Self-Polarization
7063 Force Memory Polarization
7064 Distance CVT Filter Function
7065 Distance CVT Filter T1
7066 Distance CVT Filter T2
7067 Distance CVT Filter Tx
Phase Distance (Read/Write Grouped Setting) (5 Modules)
7070 Phase Distance Zone 1 Function
7071 Phase Distance Zone 1 Current Supervision
7072 Phase Distance Zone 1 Reach
94
Range Units
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 1 --
0 to 1 --
0 to 1 ---
0 to 5 ---
0 to 1.1 pu
0 to 1 ---
0 to 600 s
0 to 3 pu
0 to 65535 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 5 ---
0 to 3 pu
0 to 600 s
0 to 600 s
0 to 65535 ---
0 to 1 ---
0 to 1 ---
0 to 5 ---
5 to 25 cycles
0 to 65535 ---
0 to 65535 ---
0 to 1 ---
0.25 to 10 ms
0.25 to 10 ms
0.25 to 10 ms
0 to 1 ---
0.05 to 30 pu
0.02 to 500 ohms
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F102 0 (Disabled)
1 F001 0
1 F102 0 (Disabled)
1 F167 0 (SRC 1)
0.001 F001 1000
1 F111 0 (Definite
Time)
0.01 F001 100
0.001 F001 100
1 F300 0
1 F102 0 (Disabled)
1 F186 0 (Phase to
Ground)
1 F001 0
1 F102 0 (Disabled)
1 F167 0 (SRC 1)
0.001 F001 1000
0.01 F001 100
0.01 F001 100
1 F300 0
1 F102 0 (Disabled)
1 F001 0
1 F167 0 (SRC 1)
1 F001 10
1 F300 0
1 F300 0
1 F102 0 (Disabled)
0.01 F001 100
0.01 F001 100
0.01 F001 100
1 F102 0 (Disabled)
0.001 F001 200
0.01 F001 200
