GE D90 Plus Communications Manual page 45

CHAPTER 2: MODBUS COMMUNICATION
Address Description
1731 Autoreclose HMI AddCause
Autoreclose 1P 3P Commands (Read/Write Command)
1740 Autoreclose SCADA Command
1741 Autoreclose HMI Command
Battery Monitor Actual Value (Read Only
17F0 Battery Voltage
Current Metering Actual Values (Read Only) (6 Modules)
1800 Source 1 Phase A Current RMS
1802 Source 1 Phase B Current RMS
1800 Source 1 Phase A Current RMS
1802 Source 1 Phase B Current RMS
1804 Source 1 Phase C Current RMS
1806 Source 1 Neutral Current RMS
1808 Source 1 Phase A Current Magnitude
180A Source 1 Phase A Current Angle
180B Source 1 Phase B Current Magnitude
180D Source 1 Phase B Current Angle
180E Source 1 Phase C Current Magnitude
1810 Source 1 Phase C Current Angle
1811 Source 1 Neutral Current Magnitude
1813 Source 1 Neutral Current Angle
1814 Source 1 Ground Current RMS
1816 Source 1 Ground Current Magnitude
1818 Source 1 Ground Current Angle
1819 Source 1 Zero-Sequence Current Magnitude
181B Source 1 Zero-Sequence Current Angle
181C Source 1 Positive-Sequence Current Magnitude
181E Source 1 Positive-Sequence Current Angle
181F Source 1 Negative-Sequence Current Magnitude
1821 Source 1 Negative-Sequence Current Angle
1822 Source 1 Differential Ground Current Magnitude
1824 Source 1 Differential Ground Current Angle
1825 Source 1 Current Reserved (27 items)
1840 Source 2 Phase A Current RMS
1842 Source 2 Phase B Current RMS
1844 Source 2 Phase C Current RMS
1846 Source 2 Neutral Current RMS
1848 Source 2 Phase A Current Magnitude
184A Source 2 Phase A Current Angle
184B Source 2 Phase B Current Magnitude
184D Source 2 Phase B Current Angle
184E Source 2 Phase C Current Magnitude
1850 Source 2 Phase C Current Angle
1851 Source 2 Neutral Current Magnitude
1853 Source 2 Neutral Current Angle
1854 Source 2 Ground Current RMS
1856 Source 2 Ground Current Magnitude
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
0 to 65535 ---
0 to 15 ---
0 to 15 ---
0 to 65535 V
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
--- ---
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
-359.9 to 0 °
0 to 999999.999 A
0 to 999999.999 A
MODBUS MEMORY MAP
Step Format Default
1 F500 0
1 F107 0 (None)
1 F107 0 (None)
1 F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
--- F001 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.1 F002 0
0.001 F060 0
0.001 F060 0
