CHAPTER 2: MODBUS COMMUNICATION
Address Description
1C6C Source 4 Phase B Reactive Power
1C6E Source 4 Phase C Reactive Power
1C70 Source 4 Three-Phase Apparent Power
1C72 Source 4 Phase A Apparent Power
1C74 Source 4 Phase B Apparent Power
1C76 Source 4 Phase C Apparent Power
1C78 Source 4 Three-Phase Power Factor
1C79 Source 4 Phase A Power Factor
1C7A Source 4 Phase B Power Factor
1C7B Source 4 Phase C Power Factor
1C80 Source 5 Three-Phase Real Power
1C82 Source 5 Phase A Real Power
1C84 Source 5 Phase B Real Power
1C86 Source 5 Phase C Real Power
1C88 Source 5 Three-Phase Reactive Power
1C8A Source 5 Phase A Reactive Power
1C8C Source 5 Phase B Reactive Power
1C8E Source 5 Phase C Reactive Power
1C90 Source 5 Three-Phase Apparent Power
1C92 Source 5 Phase A Apparent Power
1C94 Source 5 Phase B Apparent Power
1C96 Source 5 Phase C Apparent Power
1C98 Source 5 Three-Phase Power Factor
1C99 Source 5 Phase A Power Factor
1C9A Source 5 Phase B Power Factor
1C9B Source 5 Phase C Power Factor
1CA0 Source 6 Three-Phase Real Power
1CA2 Source 6 Phase A Real Power
1CA4 Source 6 Phase B Real Power
1CA6 Source 6 Phase C Real Power
1CA8 Source 6 Three-Phase Reactive Power
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to var
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-1000000000000 to VA
1000000000000
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
-0.999 to 1 ---
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to W
1000000000000
-1000000000000 to var
1000000000000
MODBUS MEMORY MAP
Step Format Default
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F013 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
0.001 F060 0
