CHAPTER 2: MODBUS COMMUNICATION
Address Description
A409 Selector 10 Position
Selector Switch Settings (Read/Write Setting) (10 Modules)
A410 Selector 1 Function
A411 Selector 1 Range
A412 Selector 1 Timeout
A413 Selector 1 Step Up
A414 Selector 1 Step Mode
A415 Selector 1 Acknowledge
A416 Selector 1 Bit0
A417 Selector 1 Bit1
A418 Selector 1 Bit2
A419 Selector 1 Bit Mode
A41A Selector 1 Bit Acknowledge
A41B Selector 1 Power Up Mode
A41D Selector 1 Events
A41E Selector 1 Reserved (10 items)
A428 ...Repeated for Selector 2
A440 ...Repeated for Selector 3
A458 ...Repeated for Selector 4
A470 ...Repeated for Selector 5
A488 ...Repeated for Selector 6
A4A0 ...Repeated for Selector 7
A4B8 ...Repeated for Selector 8
A4D0 ...Repeated for Selector 9
A4E8 ...Repeated for Selector 10
DNP/IEC Points (Read/Write Setting)
A500 DNP/IEC 60870-5-104 Binary Input Points (256 items) 0 to 65535
A600 DNP/IEC 60870-5-104 Analog Input Points (256 items) 0 to 4294967295
FlexCurve C (Read/Write Setting)
A900 FlexCurve C (120 items)
Non Volatile Latches (Read/Write Setting) (16 Modules)
AA00 Non-Volatile Latch 1 Function
AA01 Non-Volatile Latch 1 Type
AA02 Non-Volatile Latch 1 Set
AA03 Non-Volatile Latch 1 Reset
AA05 Non-Volatile Latch 1 Events
AA06 Non-Volatile Latch 1 Reserved (4 items)
AA0A ...Repeated for Non-Volatile Latch 2
AA14 ...Repeated for Non-Volatile Latch 3
AA1E ...Repeated for Non-Volatile Latch 4
AA28 ...Repeated for Non-Volatile Latch 5
AA32 ...Repeated for Non-Volatile Latch 6
AA3C ...Repeated for Non-Volatile Latch 7
AA46 ...Repeated for Non-Volatile Latch 8
AA50 ...Repeated for Non-Volatile Latch 9
AA5A ...Repeated for Non-Volatile Latch 10
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
1 to 7 ---
0 to 1 ---
1 to 7 ---
3 to 60 s
0 to 65535 ---
0 to 1 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 1 ---
0 to 65535 ---
0 to 2 ---
0 to 1 ---
--- ---
---
---
0 to 65535 ms
0 to 1 ---
0 to 1 ---
0 to 65535 ---
0 to 65535 ---
0 to 1 ---
--- ---
MODBUS MEMORY MAP
Step Format Default
1 F001 0
1 F102 0 (Disabled)
1 F001 7
0.1 F001 50
1 F300 0
1 F083 0 (Time-out)
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F083 0 (Time-out)
1 F300 0
1 F084 0 (Restore)
1 F102 0 (Disabled)
1 F001 0
1 F300 0
1 F600 0
1 F011 0
1 F102 0 (Disabled)
1 F519 0 (Reset
Dominant)
1 F300 0
1 F300 0
1 F102 0 (Disabled)
--- F001 0
