MODBUS MEMORY MAP
Address Description
A2E0 FlexElement 9 Actual
A2E2 FlexElement 10 Actual
A2E4 FlexElement 11 Actual
A2E6 FlexElement12 Actual
A2E8 FlexElement 13 Actual
A2EA FlexElement 14 Actual
A2EC FlexElement 15 Actual
A2EE FlexElement 16 Actual
Fault Report Settings (Read/Write Setting) (5 Modules)
A350 Fault Report 1 Source
A351 Fault Report 1 Trigger
A352 Fault Report 1 Z1 Magnitude
A353 Fault Report 1 Z1 Angle
A354 Fault Report 1 Z0 Magnitude
A355 Fault Report 1 Z0 Angle
A356 Fault Report 1 Line Length Units
A357 Fault Report 1 Line Length
A358 Fault Report 1 VT Substitution
A359 Fault Report 1 System Z0 Magnitude
A35A Fault Report 1 System Z0 Angle
A35B ...Repeated for Fault Report 2
A366 ...Repeated for Fault Report 3
A371 ...Repeated for Fault Report 4
A37C ...Repeated for Fault Report 5
VT Fuse Failure Settings (Read/Write Setting) (6 Modules)
A3F0 VT Fuse Failure 1 Function
A3F1 ...Repeated for VT Fuse Failure 2
A3F2 ...Repeated for VT Fuse Failure 3
A3F3 ...Repeated for VT Fuse Failure 4
A3F4 ...Repeated for VT Fuse Failure 5
A3F5 ...Repeated for VT Fuse Failure 6
Selector Switch Actual Values (Read Only) (10 Modules)
A400 Selector 1 Position
A401 Selector 2 Position
A402 Selector 3 Position
A403 Selector 4 Position
A404 Selector 5 Position
A405 Selector 6 Position
A406 Selector 7 Position
A407 Selector 8 Position
A408 Selector 9 Position
112
Range Units
-2147483.647 to ---
2147483.647
-2147483.647 to ---
2147483.647
-2147483.647 to ---
2147483.647
-2147483.647 to ---
2147483.647
-2147483.647 to ---
2147483.647
-2147483.647 to ---
2147483.647
-2147483.647 to ---
2147483.647
-2147483.647 to ---
2147483.647
0 to 5 ---
0 to 65535 ---
0.01 to 250 ohms
25 to 90 degrees 1
0.01 to 650 ohms
25 to 90 degrees 1
0 to 1 ---
0 to 2000
0 to 2 ---
0.01 to 650.00 ohms
25 to 90 degrees 1
0 to 1 ---
1 to 7 ---
1 to 7 ---
1 to 7 ---
1 to 7 ---
1 to 7 ---
1 to 7 ---
1 to 7 ---
1 to 7 ---
1 to 7 ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
0.001 F004 0
0.001 F004 0
0.001 F004 0
0.001 F004 0
0.001 F004 0
0.001 F004 0
0.001 F004 0
0.001 F004 0
1 F167 0 (SRC 1)
1 F300 0
0.01 F001 300
F001 75
0.01 F001 900
F001 75
1 F147 0 (km)
0.1 F001 1000
1 F270 0 (None)
0.01 F001 200
F001 75
1 F102 0 (Disabled)
1 F001 0
1 F001 0
1 F001 0
1 F001 0
1 F001 0
1 F001 0
1 F001 0
1 F001 0
1 F001 0
