GE D90 Plus Communications Manual page 85

CHAPTER 2: MODBUS COMMUNICATION
Address Description
4786 Synchrocheck 1 Maximum Frequency Difference
4787 Synchrocheck 1 Dead Source Select
4788 Synchrocheck 1 Dead V1 Maximum Voltage
4789 Synchrocheck 1 Dead V2 Maximum Voltage
478A Synchrocheck 1 Live V1 Minimum Voltage
478B Synchrocheck 1 Live V2 Minimum Voltage
478D Synchrocheck 1 Events
478E Synchrocheck 1 Block
478F Synchrocheck 1 Frequency Hysteresis
4790 ...Repeated for Synchrocheck 2
FlexCurve A (Read/Write Setting)
4800 FlexCurve A (120 items)
FlexCurve B (Read/Write Setting)
48F0 FlexCurve B (120 items)
FlexMatrix Inputs (Read/Write Setting)
4970 FlexMatrix Input x (16 items)
FlexMatrix (Read/Write Setting) (8 Modules)
4990 FlexMatrix 1 Function
4991 FlexMatrix 1 Block
4992 FlexMatrix 1 Events
4993 FlexMatrix 1 Enable (16 items)
49A3 FlexMatrix 1 Latching
49A4 FlexMatrix 1 Reset
49A5 FlexMatrix 1 Tpkp
49A6 FlexMatrix 1 Tdpo
49A7 FlexMatrix 1 Name
49AD FlexMatrix 1 Reserved (3 items)
49B0 ...Repeated for FlexMatrix 2
49D0 ...Repeated for FlexMatrix 3
49F0 ...Repeated for FlexMatrix 4
4A10 ...Repeated for FlexMatrix 5
4A30 ...Repeated for FlexMatrix 6
4A50 ...Repeated for FlexMatrix 7
4A70 ...Repeated for FlexMatrix 8
Battery Monitor (Read/Write Setting)
4AF0 Battery Monitor Function
4AF1 Battery Monitor Input
4AF2 Battery Monitor Block
4AF3 Battery Monitor High VDC
4AF4 Battery Monitor Low VDC
4AF5 Battery Monitor Supply Fail
4AF6 Battery Monitor Charger Fail
4AF7 Battery Monitor Bkr Trip
4AF8 Battery Monitor DC Gnd Fault
4AF9 Battery Monitor Alarm Delay
4AFA Battery Monitor Events
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
Range Units
0 to 2 Hz
0 to 5 ---
0 to 1.25 pu
0 to 1.25 pu
0 to 1.25 pu
0 to 1.25 pu
0 to 1 ---
0 to 65535 ---
0 to 0.1 Hz
0 to 655535 ms
0 to 655535 ms
0 to 65535 ---
0 to 1 ---
0 to 65535 ---
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 65535 ---
0 to 60 ---
0 to 60 ---
--- ---
0 to 6553.5 ---
0 to 1 ---
0 to 65535 ---
0 to 65535 ---
38 to 275 V
38 to 275 V
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
2 to 300 s
0 to 1 ---
MODBUS MEMORY MAP
Step Format Default
0.01 F001 1000
1 F176 1 (LV1 and
DV2)
0.01 F001 30
0.01 F001 30
0.01 F001 70
0.01 F001 70
1 F102 0 (Disabled)
1 F300 0
0.01 F001 60
1 F011 0
1 F011 0
1 F300 0
1 F102 0 (Disabled)
1 F300 0
1 F102 1 (Enabled)
1 F102 0 (Disabled)
1 F102 0 (Disabled)
1 F300 0
0.01 F001 0
0.01 F001 0
--- F205 "Flexmat 1"
0.1 F001 0
1 F102 0 (Disabled)
1 F300 0
1 F300 0
1 F001 143
1 F001 107
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F001 60
1 F102 1 (Enabled)
81
