Table 6-14. EDMA3 Transfer Controller (EDMA3TC) Registers (continued)
EDMA3_0 EDMA3_0
Transfer Transfer
Controller 0 Controller 1
BYTE ADDRESS BYTE ADDRESS
0x01C0 8280 0x01C0 8680
0x01C0 8284 0x01C0 8684
0x01C0 8288 0x01C0 8688
0x01C0 8300 0x01C0 8700
0x01C0 8304 0x01C0 8704
0x01C0 8308 0x01C0 8708
0x01C0 830C 0x01C0 870C
0x01C0 8310 0x01C0 8710
0x01C0 8314 0x01C0 8714
0x01C0 8340 0x01C0 8740
0x01C0 8344 0x01C0 8744
0x01C0 8348 0x01C0 8748
0x01C0 834C 0x01C0 874C
0x01C0 8350 0x01C0 8750
0x01C0 8354 0x01C0 8754
0x01C0 8380 0x01C0 8780
0x01C0 8384 0x01C0 8784
0x01C0 8388 0x01C0 8788
0x01C0 838C 0x01C0 878C
0x01C0 8390 0x01C0 8790
0x01C0 8394 0x01C0 8794
0x01C0 83C0 0x01C0 87C0
0x01C0 83C4 0x01C0 87C4
0x01C0 83C8 0x01C0 87C8
0x01C0 83CC 0x01C0 87CC
0x01C0 83D0 0x01C0 87D0
0x01C0 83D4 0x01C0 87D4
Table 6-15 shows an abbreviation of the set of registers which make up the parameter set for each of 128
EDMA3 events. Each of the parameter register sets consist of 8 32-bit word entries.
parameter set entry registers with relative memory address locations within each of the parameter sets.
EDMA3_0
Channel Controller 0
BYTE ADDRESS RANGE
0x01C0 4000 - 0x01C0 401F
0x01C0 4020 - 0x01C0 403F
0x01C0 4040 - 0x01CC0 405F
0x01C0 4060 - 0x01C0 407F
0x01C0 4080 - 0x01C0 409F
0x01C0 40A0 - 0x01C0 40BF
...
0x01C0 4FC0 - 0x01C0 4FDF
0x01C0 4FE0 - 0x01C0 4FFF
Copyright © 2009–2017, Texas Instruments Incorporated
EDMA3_1 ACRONYM
Transfer
Controller 0
BYTE ADDRESS
0x01E3 8280 DFCNTRLD
0x01E3 8284 DFSRCBREF
0x01E3 8288 DFDSTBREF
0x01E3 8300 DFOPT0
0x01E3 8304 DFSRC0
0x01E3 8308 DFCNT0
0x01E3 830C DFDST0
0x01E3 8310 DFBIDX0
0x01E3 8314 DFMPPRXY0
0x01E3 8340 DFOPT1
0x01E3 8344 DFSRC1
0x01E3 8348 DFCNT1
0x01E3 834C DFDST1
0x01E3 8350 DFBIDX1
0x01E3 8354 DFMPPRXY1
0x01E3 8380 DFOPT2
0x01E3 8384 DFSRC2
0x01E3 8388 DFCNT2
0x01E3 838C DFDST2
0x01E3 8390 DFBIDX2
0x01E3 8394 DFMPPRXY2
0x01E3 83C0 DFOPT3
0x01E3 83C4 DFSRC3
0x01E3 83C8 DFCNT3
0x01E3 83CC DFDST3
0x01E3 83D0 DFBIDX3
0x01E3 83D4 DFMPPRXY3
Table 6-15. EDMA3 Parameter Set RAM
EDMA3_1
Channel Controller 0
BYTE ADDRESS RANGE
0x01E3 4000 - 0x01E3 401F
0x01E3 4020 - 0x01E3 403F
0x01E3 4040 - 0x01CE3 405F
0x01E3 4060 - 0x01E3 407F
0x01E3 4080 - 0x01E3 409F
0x01E3 40A0 - 0x01E3 40BF
...
0x01E3 4FC0 - 0x01E3 4FDF
0x01E3 4FE0 - 0x01E3 4FFF
Submit Documentation Feedback
Product Folder Links: TMS320C6748
SPRS590G – JUNE 2009 – REVISED JANUARY 2017
REGISTER DESCRIPTION
Destination FIFO Set Count Reload Register
Destination FIFO Set Source Address B-Reference
Register
Destination FIFO Set Destination Address B-Reference
Register
Destination FIFO Options Register 0
Destination FIFO Source Address Register 0
Destination FIFO Count Register 0
Destination FIFO Destination Address Register 0
Destination FIFO B-Index Register 0
Destination FIFO Memory Protection Proxy Register 0
Destination FIFO Options Register 1
Destination FIFO Source Address Register 1
Destination FIFO Count Register 1
Destination FIFO Destination Address Register 1
Destination FIFO B-Index Register 1
Destination FIFO Memory Protection Proxy Register 1
Destination FIFO Options Register 2
Destination FIFO Source Address Register 2
Destination FIFO Count Register 2
Destination FIFO Destination Address Register 2
Destination FIFO B-Index Register 2
Destination FIFO Memory Protection Proxy Register 2
Destination FIFO Options Register 3
Destination FIFO Source Address Register 3
Destination FIFO Count Register 3
Destination FIFO Destination Address Register 3
Destination FIFO B-Index Register 3
Destination FIFO Memory Protection Proxy Register 3
DESCRIPTION
Parameters Set 0 (8 32-bit words)
Parameters Set 1 (8 32-bit words)
Parameters Set 2 (8 32-bit words)
Parameters Set 3 (8 32-bit words)
Parameters Set 4 (8 32-bit words)
Parameters Set 5 (8 32-bit words)
...
Parameters Set 126 (8 32-bit words)
Parameters Set 127 (8 32-bit words)
Peripheral Information and Electrical Specifications
TMS320C6748
Table 6-16 shows the
