ESC GS BEL m t1 t2
Format: ASCII: ESC GS BEL m t1 t2
Decimal: 27
Hex: 1B
Description:
1≤m≤2, 49≤m≤50 ("1"≤m≤"2")
1≤t1≤255
1≤t2≤255
Rings the buzzer.
m specifies the drive terminal of the buzzer.
• Energizing time = 20 msec x t1
• Delay time = 20 msec x t2
ESC GS EM DC1 m n1 n2
Format: ASCII: ESC GS EM DC1 m n1 n2
Decimal: 27
Hex: 1B
Description:
1≤m≤2 49≤m≤50
0≤n1≤255
0≤n2≤255
Sets external buzzer derive pulse condition.
* Energizing time = 20 msec x n1
* Delay time = 20 msec x n2
ESC GS EM DC2 m n1 n2
Format: ASCII: ESC GS EM DC2 m n1 n2
Decimal: 27
Hex: 1B
Description:
1≤m≤2 49≤m≤50
1≤n1≤20
n2=0
Repeatedly drives the buzzer according to the ON/OFF conditions set by the external buzzer drive pulse
conditions command <ESC> <GS> <EM> <DC1> m t1 t2.
CODESOFT PL-330 User's Manual
29 7 m t1 t2
1D 07 m t1 t2
m Buzzer Drive Terminal
1, 49 Buzzer Drive Terminal 1
2, 50 Buzzer Drive Terminal 2
29 25 17 m n1 n2
1D 19 11 m n1 n2
m Buzzer Drive Terminal
1, 49 Buzzer Drive Terminal 1
2, 50 Buzzer Drive Terminal 2
29 25 18 m n1 n2
1D 19 12 m n1 n2
m Buzzer Drive Terminal
1, 49 Buzzer Drive Terminal 1
2, 50 Buzzer Drive Terminal 2
External buzzer drive pulse condition settings
External buzzer drive execution
- 85 -
Ring buzzer
