ESC b n1 n2 n3 n4 d1...dk RS
Format: ASCII: ESC b
Decimal: 27
Hex: 1B
Description:
0≤n1≤8, 48≤n1≤56 ("0"≤n1≤"8")
1≤n2≤4, 49≤n2≤52 ("1"≤n2≤"4")
1≤n4≤255
n3 (bar code mode), n4 bar code height (dot count), d (bar code data), k (bar code data count) definitions
differ according to the type of bar code.
Bar code printing is executed according to the following parameters.
n2 Under-bar character selection and added line feed selection
1, 49 No added under-bar characters Executes line feed after printing a bar code
2, 50 Adds under-bar characters Executes line feed after printing a bar code
3, 51 No added under-bar characters Does not execute line feed after printing a bar code
4, 52 Adds under-bar characters Does not execute line feed after printing a bar code
ESC d n
Format: ASCII: ESC d
Decimal: 27
Hex: 1B
Description:
0≤d≤3
48≤d≤51 ("0"≤d≤"3")
Executes the auto-cutter.
n
Full cut at the current position.
0, 48 Print data in line buffer is printed before a full cut.
This command is ignored if the printer is not equipped with an auto-cutter.
Partial cut at the current position.
1, 49 Print data in line buffer is printed before a partial cut.
This command is ignored if the printer is not equipped with an auto-cutter.
Paper is fed to cutting position, then a full cut.
2, 50 Print data in line buffer is printed before the operation described above.
This command is ignored if the printer is not equipped with an auto-cutter.
CODESOFT PL-330 User's Manual
2, 50
3, 51 Double high/wide mode
n1 n2 n3 n4 d1 ... dk RS
98 n1 n2 n3 n4 d1 ... dk 30
62 n1 n2 n3 n4 d1 ... dk 1E
n1
0, 48
1, 49
2, 50
3, 51
4, 52
5, 53
6, 54
n
100 n
64 n
Double high mode
Bar code type
UPC-E
UPC-A
JAN/EAN8
JAN/EAN13
Code39
ITF
Code128
Auto cutter
- 83 -
Print bar code
Auto-cutter
