The setting of Security Mode and Encrypt Type
Refer to "Connecting the Printer", connect the wireless equipment with the printer and select the
parameters acquired by the above steps in the "Security Mode" and "Encrypt Type" of the "AP
Client".
Pass Phrase: The password of the hotspot
Address Assignment: It includes "DHCP (Auto config)" and "Static (Assigned IP)". You can select the
CODESOFT PL-330 User's Manual
The current Wi-Fi hotspot of this example.
corresponding assignment way according to your need. When selecting "DHCP
(Auto config)", the IP Address and Subnet Mask can be acquired automatically
(Click "Apply" and the system will assign automatically), and there is no need to
set manually (as shown in Figure 15).
Figure 14
- 26 -
