ESC $
Format: ASCII:
Decimal:
Hex:
Description:
Set the distance from the beginning of the line to the print position. The distance is (nL+nH*256)* (horizontal
or vertical minimal unit). nL, nH=0~255.
Horizontal or vertical minimal unit are specified by GS P command.
ESC %
Format: ASCII:
Decimal:
Hex:
Description:
n=1, Select the user-defined characters set; n=0, Select inner characters set.
Default: n=0
ESC &
Format: ASCII:
Decimal:
Hex:
Description:
Define the user-defined characters from c1 to c2.
y=3; 32≤c1≤c2≤126;
0≤x≤12; [Character A 12*24], 0≤x≤9; [Character B 8*16];
d=0~255; k=c2-c1+1;
y specifies the number of bytes in the vertical direction, x specifies the number of dots in the horizontal
direction, d specifies the user-defined character.
ESC *
Format: ASCII:
Decimal:
Hex:
Description:
Select the image mode with m; n1 and n2 specify the number of dots. The image data d1...dk
m=0, 1, 32, 33; n1=0~255; n2=0~3; d=0~255.
k=n1+256×n2 (m=0, 1)
k= (n1+256×n2) × 3 (m=32, 33)
The number of dots in horizontal direction is n1+256×n2.
If the number of dots exceeds one line, the part which exceeds the maximum number of dots (shown as
below) is ignored.
M is used to select the dot image way.
M Mode
8-dot
0
single-density
CODESOFT PL-330 User's Manual
ESC $
27 36
1B 24
ESC %
27 37
1B 25
ESC & y c1 c2
27 38 y c1 c2
1B 26 y c1 c2
ESC * m
27 42 m
1B 2A m
Vertical
Number Dot
of dots density
8 68 DPI
nL nH
nL nH
nL nH
Select/cancel user-defined characters set
n
n
n
[x1 d1..d(y*x1)]
[x1 d1..d(y*x1)]
[x1 d1..d(y*x1)]
n1 n2 d1..dk
n1 n2 d1..dk
n1 n2 d1..dk
Dot
density
101 DPI
- 58 -
Set absolute print position
Define user-defined characters
[xk d1..d(y*xk)]
[xk d1..d(y*xk)]
[xk d1..d(y*xk)]
Select bit-image mode
Horizontal
Number of dots (Max)
288
