2.1 Unpacking and Checking

Check the following items in the package, if any of these items is missing, please contact your dealer.
Printer
Note: 1. Models with Bluetooth and Wi-Fi are not equipped with interface cable.
2. Roll paper guide is equipped according to the necessity of the customers.

2.2 Removing the Protective Materials

1. Open the packing box, take out the printer.
2. Save all the original packing materials so that they can be used when transporting the printer in the
future.

2.3 Connecting to Your Computer or Other Equipment

The printer is configured with a cash drawer interface and one data interface (you can select Parallel
interface, USB interface, USB interface + Serial interface, USB interface + Ethernet interface, USB
interface + Serial interface + Ethernet interface, USB interface + Bluetooth or Wi-Fi). Please take the
specific interface as standard. Connect the printer to your computer with the correct cable.
Note: Before connecting the cash drawer cable, parallel cable or serial cable, make sure that
the power of the printer is turned off. Only after tightening the cable may you turn on
the printer. Or else the printer may be damaged.

2.3.1 Connecting the Cash Drawer Cable

Turn off the printer and plug one end of the cash drawer cable into the cash drawer interface of the
printer and the other end to the cash drawer. (As shown in Figure 2-2)
CODESOFT PL-330 User's Manual

Chapter 2 Installing the Printer

Power cord
Roll paper guide (Optional)
Figure 2-1 Packing list
Interface cable (Optional)
Driver CD
(Including User's Manual and Driver)
- 3 -
AC adapter
