1.1 Features

CODESOFT PL-330 is a high-speed thermal printer. It is a high-quality, high-reliability and low-noise
POS printer without ribbon. It's small, easily-operated and can be widely used in ECR, PC-POS and
BANK POS for printing a variety of receipts.

1.2 Product Model Description

In order to fulfill different requirements and operating circumstance, manufacturer develops
CODESOFT PL-330 series products which are high-speed thermal mini-printers.
CODESOFT PL-330 series products are equipped with auto cutter, so that customer could select full
cut or partial cut.
Interface:
CODESOFT PL-330 series products are configured with cash drawer interface, you can choose one
of the following data interfaces when purchasing this product:
● Parallel interface (PL-330D)
● USB interface (PL-330S)
● USB interface + Serial interface (PL-330US)
● USB interface + Ethernet interface (PL-330UE)
● USB interface + Serial interface + Ethernet interface (PL-330USE)
● USB interface + Bluetooth (PL-330UB)
● Wi-Fi (PL-330W)
Note: Please contact the local dealer to change the interface if needed with added expense.

1.3 Main Parts of the Printer

POWER LED
ERROR LED
PAPER OUT LED
CODESOFT PL-330 User's Manual

Chapter 1 Overview

Figure 1-1 Main parts of the printer
- 1 -
Upper cover
Case
Cover-open button
FEED button
