Note: Please refer to the user's manual for detailed instructions of network settings.

2.4 Connecting the Power

1. Make sure the printer is turned off. (The pressed down side on the switch with "O" mark denotes the
printer is off)
2. Make sure the voltage of the electrical outlet matches that of the AC adapter.
3. Plug the AC adapter to the printer's power supply inlet.
4. Plug one end of power cord into the AC adapter, and then plug the other end of the power cord into
the grounded electrical outlet.
Warning: 1. If the rated voltage doesn't match the outlet voltage, contact your dealer
2. Please use the electrical outlet connecting the ground properly.
3. Please use the original AC adapter only. Manufacturers have no
CODESOFT PL-330 User's Manual
Ethernet cable
Figure 2-6 Connecting the Ethernet cable
Figure 2-7 Connecting the power
for assistance. Do not plug the power cord to electrical outlet.
responsibilities for the problems which are led by using unauthorized AC
adapter.
Ethernet interface
Power supply inlet
AC adapter
- 6 -
Power cord
