Code Soft PL-330D User Manual page 70

FS S
Format: ASCII:
Decimal:
Hex:
Description:
0≤n1≤255, 0≤n2≤255 Set the character left-side spacing to n1* horizontal motion unit, right-side spacing to
n2* horizontal motion unit.
FS W
Format: ASCII:
Decimal:
Hex:
Description:
0≤n≤255
When the last bit of n is 0, turn off the quadruple-size mode.
When the last bit of n is 1, turn on the quadruple-size mode.
FS p n m
Format: ASCII:
Decimal:
Hex:
Description:
1≤n≤64 m=0, 1, 2, 3, 48, 49, 50, 51 Prints the NV bit image according to the mode specified by m.
m=0, 48 Normal printing; m=1, 49 Double width printing;
m=2, 50 Double height printing; m=3, 51 Quadruple-size printing.
FS q n
Format: ASCII: FS
Decimal: 28
Hex: 1C
Description:
1≤n≤64; xH=0; 0≤xL≤72; yH=0; 0≤yL≤30
k= (xL+xH*256)*(yL+yH*256)*8
The command can define 64 bit images at the same time. All NV images preciously defined are canceled
when new bit image defined. After executing this command, ERROR LED will be on for a period of time,
then the PAPER OUT LED and ERROR LED will be both on and the printer restarts. No other data or
commands follow this command, or it may cause data lost or messy code. The NV image data will be stored
in the printer even when printer is powered off, and will not lose till the image is redefined. In order not to
damage the printer, the command should not be defined more than 10 times per day. The whole command
including the bit image data should be less than 128K bytes (1M bits).
xL,xL specifies the number of bytes in the horizontal direction for the NV bit image and the limited width is
72 bytes and 576 dots.
yL,yH specifies the number of bytes in the vertical direction for the NV bit image with the height of 30 bytes
and 240 dots.
d specifies the data for the NV bit image(column format).
GS BEL n1 n2
Format: ASCII:
Decimal:
Hex:
Description:
CODESOFT PL-330 User's Manual
FS S n1 n2
28 83 n1
1C 53 n1
FS W n
28 87 n
1C 57 n
FS p n m
28 112 n m
1C 70 n m
q n [xL xH yL yH d1 d2 ...dk] 1... [xL xH yL yH d1 d2 ...dk
113 n [xL xH yL yH d1 d2 ...dk] 1... [xL xH yL yH d1 d2 ...dk]
70 n [xL xH yL yH d1 d2 ...dk] 1... [xL xH yL yH d1 d2 ...dk]
GS BEL n1
29 7 n1
1D 07 n1
n2
n2
Turn quadruple-size mode on/off for Chinese character
n2 n3
n2 n3
n2 n3
- 64 -
Set Chinese character spacing
Print NV bit image
Define the NV bit image
Beep for appointment
