Code Soft PL-330D User Manual page 83

HT
Format: ASCII:
Decimal:
Hex:
Description:
Move print position to next horizontal tab position.
ESC D n1 n2...nk NUL
Format: ASCII:
Decimal:
Hex:
Description:
1≤n≤255
0≤k≤16
Uses the left edge as a standard to set the horizontal tab to the position of (current ANK character pitch x n).
ESC D NUL
Format: ASCII:
Decimal:
Hex:
Description:
Clears the currently set horizontal tab.
ESC GS A n1 n2
Format: ASCII:
Decimal:
Hex:
Description:
0≤n1≤255
0≤n2≤255
Moves the printing position from the left margin to the (n1+n2x256) position.
This command is ignored if the print region is exceeded.
ESC GS R n1 n2
Format: ASCII:
Decimal:
Hex:
Description:
0≤n1≤255
0≤n2≤255
Moves the printing position from the current position to the (n1+n2x256) position.
ESC GS a n
Format: ASCII:
Decimal:
Hex:
Description:
0≤n≤2
48≤n≤50 ("0"≤n≤"2")
Specifies the alignment position in the printing region that has been set.
CODESOFT PL-330 User's Manual
HT
9
09
ESC D n1 n2 ... nk NUL
27 68 n1 n2 ... nk 0
1B 44 n1 n2 ... nk 00
ESC D NUL
27 68 0
1B 44 00
ESC GS A n1 n2
27 29 65 n1 n2
1B 1D 41 n1 n2
ESC GS R n1 n2
27 29 82 n1 n2
1B 1D 52 n1 n2
ESC GS a n
27 29 97 n
1B 1D 61 n
- 77 -
Move horizontal ta
Set horizontal tab
Clear horizontal tab
Move absolute position
Move relative position
Specify position alignment
