CODESOFT PL-330 User's Manual

Chapter 4 Installing Paper

The printer can use the paper with the width of 79.5±0.5mm and 57.5±0.5mm conveniently. How to
install the paper will be explained in details in this chapter.
Installing
4.1 Thermal Paper
Steps
Caution: 1. Don't touch the thermal print head after printing to avoid getting hurt.
2. Don't pull the paper out directly with your hand.
1. Press the cover-open button to open the upper cover. If you want to use 57.5mm paper to print, you
must install the roll paper guide firstly.
Upper cover
Figure 4-1 Opening the printer cover
Roll paper guide (Optional)
Figure 4-2 Installing the roll paper guide (Optional)
2. Place the roll paper into the paper holder and pull out a small amount of paper.
- 47 -
