*70 ITF
*71 CODABAR
*73 CODE128
GS v 0
Format: ASCII:
Decimal:
Hex:
Description:
Print a raster bit image according to the numerical value of m.
m=0, 48: normal printing; m=1, 49: double width printing; m=2, 50: double height printing; m=3, 51:
quadruple-size printing.
XL, xH, yL, yH=0~255.
The number of bytes in horizontal printing: xL+xH*256;
The number of dots in vertical printing: yL+yH*256.
k= (xL+xH*256)*(yL+yH*256)
GS w
Format: ASCII:
Decimal:
Hex:
Description:
Set the transverse size of barcode.
2≤n≤6.

7.2.2 STAR Line Mode Printing Commands

ESC RS F n
Format: ASCII:
Decimal:
Hex:
Description:
0≤n≤1
Selects a font
ESC GS t n
Format: ASCII:
Decimal:
Hex:
Description:
0≤n≤21
32≤n≤34
64≤n≤79
CODESOFT PL-330 User's Manual
Can be changed 1≤n≤255 (even)
Can be changed
Can be changed
GS v 0
29 118 48
1D 76 30
GS w n
29 119 n
1D 77 n
ESC RS F n
27 30 70 n
1B 1E 46 n
n
0
1
ESC GS t
27 29 116 n
1B 1D 74
0～9, A～D,
1≤n≤255
$, +, -,., /, :
NUL ～ SP
2≤n<255
(7FH)
m xL xH yL
m xL xH yL
m xL xH yL
Font
Font-A (12x24 dots)
Font-B (9x24 dots)
n
n
- 68 -
0～9 48≤d≤57
48≤d≤57, 65≤d≤68, 36,
43, 45, 46, 47, 58
0≤d≤127
Print raster bit image
yH d1...dk
yH d1...dk
yH d1...dk
Set the transverse size of barcode
Select code page
Select font
