Code Soft PL-330D User Manual page 90

Paper is fed to cutting position, then a partial cut.
3, 51 Print data in line buffer is printed before the operation described above.
This command is ignored if the printer is not equipped with an auto-cutter.
ESC BEL n1 n2
Format: ASCII: ESC BEL n1 n2
Decimal: 27
Hex: 1B
Description:
1≤n1≤127
1≤n2≤127
Sets the energizing and delay times for drive of the external device.
* Energizing time = 10 x n1 (ms)
* Delay time = 10 x n2 (ms)
BEL
Format: ASCII: BEL
Decimal: 7
Hex: 07
Description:
Executes the external device drive
FS
Format: ASCII: FS
Decimal: 28
Hex: 1C
Description:
Executes the external device drive conditions set according to the command to set the external drive device
pulse width (ESC BEL n1 n2).
SUB
Format: ASCII: SUB
Decimal: 26
Hex: 1A
Description:
Drives external device 2.
The energizing time and delay time for the external device 2 are fixed at 200 ms each.
EM
Format: ASCII: EM
Decimal: 25
Hex: 19
Description:
Drives external device 2.
The energizing time and delay time for the external device 2 are fixed at 200 ms each.
CODESOFT PL-330 User's Manual
7 n1 n2
07 n1 n2
Set external drive device 1 pulse width
External device 1 drive instruction
External device 1 drive instruction
External device 2 drive instruction
External device 2 drive instruction
- 84 -
