Mobile Equipment Wi-Fi Printing Function Application; The System Print Service Application Of Android Equipment - Code Soft PL-330D User Manual

After turning on the printer, the Wi-Fi LED blinks fast, which denotes the interface is in the ON status.
30 seconds later, the Wi-Fi LED blinks slowly, which denotes the Wi-Fi interface is in normal working
condition.
If user needs to restore the Wi-Fi parameters to factory default setting; just press the Wi-Fi RESET
button to do it in a quick way. The method is as below:
1. Turn on the printer, wait for a few seconds until the Wi-Fi LED blinks slowly, and then press down the
Wi-Fi RESET button for 2 seconds. Loosen the button and the LED blinks twice fast then blinks
slowly again.
2. Reboot the printer and the factory default settings have been restored.

2.10 Mobile Equipment Wi-Fi Printing Function Application

The CODESOFT printer which is equipped with Wi-Fi interface supports the print service of Android
system 4.4 or above version and the AirPrint wireless printing function of iPhone iOS system. After the
Android mobile equipment has installed the CODESOFT print service plug-in, it can directly use the
system print service to realize wireless printing; the iPhone iOS equipment does not need to install any
plug-in.
Note: 1. Only if wireless printing function is supported by the APP can it be used.
2. The Android system must be 4.4 or above version and should have the complete
Android Print function.
Wireless Printer which is equipped with Wi-Fi interface is taken as an example to describe printing
application. Network name (SSID) is "Wireless Printer", IP Address is 10.10.10.1, Subnet Mask is
255.255.255.0 and Security Mode is "Disable". Turn on the printer and then conduct the subsequent
application steps. As shown in Figure 17.

2.10.1 The System Print Service Application of Android Equipment

As the Android system is relatively open, the equipment manufacturers can customize the special
interface and function according to their need. The parameter setting way may be different because of
the different interfaces.
CODESOFT PL-330 User's Manual
Figure 17
- 28 -
