Power Supply
(AC adapter)
Power input
Environmental
conditions
Weight
Noise
Physical dimensions
Power consumption
Code page
Control panel
Paper type
Certificate
Note: All the technical instructions in this user's manual are the laboratorial measurements
which are achieved under national standard store and work environment (room
temperature), the measuring paper accords with the specification in this user's
manual.
Note: In order to ensure the printer life, strictly prohibit printing full line and full black
exceeding 2 CM.
CODESOFT PL-330 User's Manual
Dot image printing command: Support different densities dot images and
Linear bar code: UPC-A, UPC-E, EAN-13, EAN-8, CODE39,
Bar code
Two-dimension code: PDF417, QR CODE
Voltage: 100 ~ 240 V (AC)
IN
Frequency: 50Hz/60Hz
Voltage: 24 V (DC)
OUT
Current: 2.5 A
Input voltage: 24 V (DC)
Current: 2.5 A
Warning: Please use the original AC adapter only.
Parameters
Operating environment
Storage environment
Approx.1.45 kg
＜38 dB (A) (ISO7779 standard)
148 mm (width) × 207 mm (depth) × 135 mm (height)
① Operating: 40 W; ② Standby: Approximately 3.5 W
Note: Only when the product is unconnected with outer power
supply, can it achieve zero energy consumption state.
ESC/POS (77 kinds)
STAR Line Mode (42 kinds)
1 key and 3 LED indicators
Thermal roll paper
CE
downloading image printing, can save NV
bitmap without electricity (Can save LOGO for
long)
CODE128, ITF-25, CODABAR
Manufacturers have no responsibilities
for the problems which are led by using
unauthorized AC adapter.
Temperature: 5 ~ 35℃
Humidity: 25 ~ 80%RH (No condensation)
Temperature: -40 ~ 55℃
Humidity: ≤93%RH (40℃, no condensation)
