Ethernet Settings; Connecting The Printer; Setting Ip Address - Code Soft PL-330D User Manual

2.8 Ethernet Settings

Note: The network printing function needs the operation systems of Windows2000 and
above and the operation systems of Window 98/ME and below are not supported.

2.8.1 Connecting the Printer

Power on the printer, connect with the Ethernet interface cable which has been connected to LAN,
and look into the information of Ethernet LED to ensure the printer has entered the normal
connection.

2.8.2 Setting IP Address

1. Running NetFinder Software
Double click NetFinder.exe in the PC which connects the printer in the same LAN. The figure of the
software is shown as follows:
Button description:
Exit — Exit from the software
Search — Search printers in the same LAN
Assign IP — Modify the IP address and other settings for the specified printer.
2. Searching the Printer
Click "Search" button in the main interface, the dialog box appearing will begin searching
automatically and displays the status, listing a printer in the main interface if found. The time is
counting down in the progress bar (10s in total) and the search will finish as soon as the time is over.
If you need to go on searching, press "Search" button again.
CODESOFT PL-330 User's Manual
Orange LED
On
Off
Green LED
Blink
Off
- 12 -
Description
Online
Offline
