Code Soft PL-330D User Manual page 72

GS B
Format: ASCII:
Decimal:
Hex:
Description:
When the last bit of n is 0, turn the white/black reverse mode off.
When the last bit of n is 1, turn the white/black reverse mode on.
GS H
Format: ASCII:
Decimal:
Hex:
Description:
n=0, 48: NO HRI printing. n=1, 49: above the barcode.
n=2, 50: above the barcode. n=3, 51: Both above and below.
GS L
Format: ASCII:
Decimal:
Hex:
Description:
Set the distance between print position and left margin is (nL+nH*256)*(horizontal or vertical minimal unit);
nL, nH=0~255.
Horizontal or vertical minimal unit is specified by GS P command.
GS P
Format: ASCII:
Decimal:
Hex:
Description:
Set the horizontal and vertical minimal unit to 1/x inch and 1/y inch.
When x or y=0, the default setting 1/203 inches is selected.
GS V
Format: ASCII:
Decimal:
Hex:
Description:
(The command can only realize full cut or partial cut according to the cutter type.)
m=0, 48; No n parameter, Executes a full cut.
m=1, 49; No n parameter, Executes a partial cut (with one point left in the middle).
m=6, n=0~255; Feed paper to n*(vertical minimal unit) and executes a full cut.
m=66, n=0~255; Feed paper to n*(vertical minimal unit) and executes a partial cut.
GS W
Format: ASCII:
Decimal:
Hex:
Description:
Set the print area width to (nL+nH*256)* (horizontal or vertical minimal unit),
CODESOFT PL-330 User's Manual
GS B n
29 66 n
1D 42 n
GS H
29 72 n
1D 48
GS L nL
29 76 nL
1D 4C nL
GS P x y
29 80 x y
1D 50 x y
GS V m (n)
29 86 m (n)
1D 56 m (n)
GS W nL
29 87 nL
1D 57 nL
Enable/disable the printer to print HRI character
n
n
nH
nH
nH
nH
nH
nH
- 66 -
Turn white/black reverse mode on/off
Set horizontal or vertical minimal unit
Select cut mode and cut paper
Set print area width
Set left margin
